A sparse matrix is one with a large proportion of zero elements. Many important algorithms involve multiplying a sparse matrix by a vector, . This key computational ``kernel'' is the focus of the main laboratory project for this course.

Applications include:

- Solving partial differential equations on unstructured (tetrahedronal) meshes - for example to simulate fluid flow
- Calculating the eigenvalues of the web's hyperlink connectivity graph, for example in order to compute Google's ``Pagerank''
- Solving a Markov process - derive the probability of a system being in a particular state, given a matrix of state transition probabilities.

double A[A_rows][A_cols]; double x[A_rows], y[A_rows]; for ( i=0; i<A_rows; i++ ) { sum = 0.0; for ( k=1; k<=A_cols; k++ ) sum += A[i][k]*x[k]; y[i] = sum; }To make this sparse we need to choose a storage scheme. A popular choice is ``compressed row'':

struct MatrixElement { long col; double val; }; /* no of non-zeroes in each row */ int SA_entries[A_rows]; /* array of pointers to list of non-zeroes in each row */ MatrixElement** SA = (struct MatrixElement**)malloc(sizeof(struct MatrixElement)*A_rows); /* When SA_entries is known we can allocate just enough memory for data */ for(i=0; i<A_rows; i++) { SA[i] = (struct MatrixElement*)malloc(sizeof(struct MatrixElement)*A_entries[i]); }The idea here is that for each row, we keep an array of the non-zero matrix elements, pointed to by

`SA[i]`

. For each element
`SA[i][j]`

we need its value, and its column number. So, if
`A[i][j]`

is the `n`

th non-zero in row `i`

, its value
will be stored at `SA[i][n].val`

, and `SA[i][n].col`

will be
`j`

.
Now the matrix-vector multiply can be written as:

for(i=0; i<A_rows; i++) { sum = 0; for(j=0; j<SA_entries[i]; j++) { sum += ((SA[i][j]).val)*x[(SA[i][j]).col]; } y[i] = sum; }

You can find the source code in

/homes/phjk/ToyPrograms/C/smv-V1Copy this directory tree to your own directory:

cd cp -r /homes/phjk/ToyPrograms/C/smv-V1 ./Now run some setup scripts:

cd smv-V1 source SOURCEME.csh ./scripts/PutInputFilesOnLocalDisk.sh ./scripts/MakeMatrices.sh 1 2 3This creates a directory /tmp/USERNAME/spmv/ and builds some sample matrices there. You should compile the application using the following commands:

cd solver/csteady/ makeNow you can run the program:

./csteady ../../inputs/courier1/ ../../inputs/courier1/STEADYThis reads input from the directory for problem size 1, and writes its output to a file called ``STEADY'' in the same directory. This is problem size 1 - very tiny. Problem size 3 is more substantial.

- Choose a linux machine on the DoC network
^{2}and measure the execution time of csteady on problem size 3.Try to make sure no other processes are active as they will interfere with your results. How many times do you need to repeat your experiments to get a reliable result?

- Use the cachegrind simulator to estimate csteady's cache performance:
cachegrind ./solver/csteady/csteady inputs/courier1/ inputs/courier1/STEADY

- Plot a graph that shows how the rate of level-1 data cache misses
changes with cache size using problem size 1.
Start with:
cachegrind --L2=64,1,16 ./solver/csteady/csteady inputs/courier1/ inputs/courier1/STEADY}

This simulates a 1-way (ie direct-mapped) cache with 64, 16 byte lines. Now replace 64 with powers of two up to . See below for hints on how to automate this.

The program solves a Markov chain derived from a probabilistic Petri model (see see Figure 1) of a simple communication protocol. The problem size corresponds to the protocol's ``window size'' - the number of messages which can be in sent before the transmitter blocks awaiting acknowledgement. Execute the following commands to see the final results:

cd inputs/courier1 ./perfThe output shows the values for the following metrics of the protocol's performance:

**psend:**- Probability that the sender's application level is idle
**precv:**- Probability that the receiver's application level is idle
**psess1:**- Probability that the sender's session level is idle
**psess2:**- Probability that the receiver's session level is idle
**ptransp1:**- Probability that the sender's transport level is idle
**ptransp2:**- Probability that the receiver's transport level is idle
**lambda:**- data throughput rate of the protocol

Run cachegrind over a range of parameters you need to write a shell script. You might find the following Bash script useful:

#!/bin/bash -f for ((x=64; x <= 1048576 ; x *= 2)) do echo -n ``Size $x `` cachegrind --D1=$x,1,16 ./solver/csteady/csteady inputs/courier1/ inputs/courier1/STEADY \ 2>&1 | grep ``D1 miss rate'' done(The final line combines stdout and stderr and selects just the D1 miss rate from the simulation output). You can run this script by typing

./scripts/cg-loop.sh > resultsThis writes all the results to a file ``results''. It takes quite a while!

You need to convert the ``results'' file to a neat table of problem size against performance. Try:

awk '{print $2, $6, $8, $10}' <results > tableThis picks out the miss rate data columns. The output is sent to the file ``table''.

Try using the gnuplot program. Type ``gnuplot''. Then, at its prompt type:

plot 'table' with linespoints plot 'table' using 0:2 with linespoints, 'table' using 0:3 w lp, 'table' u 0:4 w lp

*Paul Kelly, Imperial College London, 2004*
